2-Axis Lathe DRO without Readout Box
Select the inch/metric option to match the DRO handhweels to your machine’s leadscrew pitch. All ball screw machines use a metric pitch.
This kit was developed for those who already have a digital readout installed on their mill and wish to add a DRO to their lathe without duplicating the electronics box. This cost-saving measure allows you to switch the box back and forth between the lathe and mill.
NOTE: The DRO can be ordered on any new machine as a factory installed option. The digital readout handwheels replace the standard handwheels that would normally come with the machine. If you purchase a machine with factory installed DRO, the regular handwheels are not included. If you purchase the DRO as a separate option and install it yourself, you will have the stock handwheels left over.
Download PDF 8200 Instructions
|81320||2″ DRO X-Axis Handwheel (metric 81322)|
|81340||2.5″ DRO Y-Axis Handwheel (metric 81342)|
|81100||Encoder Units (Tested) w/Cable|
|81300||DRO X/Y-Axis Thrust Collar|
|81508||DRO Lead Screw Thrust|
|81500||DRO Tachometer Encoder w/Cable|
|81510||6-pulse DRO Tachometer Pickup Decal (leadscrew machines only)|
|68060||5-pulse DRO Tachometer Pickup Decal (ball screw machines only)|
|81080||Black Tie 4″ Wrap|
